Neonatal Incubator Control System

Medical-grade neonatal incubator controller built to IEC 60601-2-19. Dual-thermistor PID control, 45-min battery backup, audit-traceable event log.

Domain
Embedded Medical
Technology
ARM Cortex-M7 · PID Control · Medical Device · Embedded
Standards
IEC 60601-2-19
System Components
01
Sensor Box

Dedicated enclosure housing all environmental sensors. Readings are sampled continuously and transmitted to the mainboard.

Interface
I²C / UART
Sample Rate
1 Hz
Location
Inside chamber
Sensors
Temperature · Humidity · Oxygen
Control Interface

7-inch capacitive touch display. Dual-thermistor servo control — operators monitor skin and air temperature independently with real-time setpoint comparison and heater output feedback.

NEONATAL INCUBATORSERVO AIR● NORMAL09:41:22
SKIN TEMP
36.5°C
SET  37.0°C
AIR TEMP
36.8°C
SET  37.0°C
HUMIDITY
58.4%
SP 58%
OXYGEN
21.1%
SP 21%
WEIGHT
3.24kg
no setpoint
HEATER OUTPUT
72%
● HTR● SENSOR● PWR
SKIN SP ▲
SKIN SP ▼
AIR SP ▲
AIR SP ▼
HUMID ▲
HUMID ▼
ALARM LOG
MENU
Certifications

The system has passed all mandatory regulatory tests conducted by accredited testing bodies in Indonesia.

PASSED
IEC 60601-2-19
Performance Test
Infant incubator performance & essential safety requirements
Testing BodyBPAFK
PASSED
IEC 60601-1
Electrical Safety
General requirements for basic safety of medical electrical equipment
Testing BodyBPAFK
PASSED
IEC 61000
EMC Test
Electromagnetic compatibility — emissions & immunity
Testing BodyBPAFK
